| Configuration parameter | CPU | RK3288 Quad Core Cortex-A17 Quad Core GPU Mali-T764 |
| Heat dissipation method | Fanless passive cooling method | |
| DDR | 2G DDR3 (optional 4G) | |
| Hard disk | 16G eMMC (optional/32G/64G) | |
| I/O interface |
3*USB2.0 1*USB-OTG |
|
| 1*RJ 45(10M/100M adaptive Ethernet) | ||
|
headphone holder::3.5mm standard interface 2*RS232 Wifi+Bluetooth |
||
| Speaker | Support | |
| Power supply | Power input | POE |
| Display | LCD screen | 10.1" LED backlit screen |
| Resolution | 1280*800 16：10 | |
| brightness | 250cd/m | |
| Touch screen | Touch mode | Capacitive touch screen |
| System | system | Android 8.1 and above |
| Surroundings | Operating temperature | -10 °C 〜60 °C |
| storage temperature | -20 °C-70 °C | |
| Airtight level | Front panel IP46 dustproof and waterproof | |
| colour | Black/Silver | |
| NFC card reader | NFC card reader |
1.3 automatic card reading methods 2.3.3V-5V wide voltage power supply 3. Fast card reading, up to 30 times per second |
| İntegrated 2D barcode scanener | 2D barcode scanener | Support |
