10.1inch Industrial cheap touch panel pc IP65 Waterproof Wall mounted Embedded Tablet Computer price
Size:10.1"
Model:HX-101-IPC02
HX-101-IPC02 is a 10.1-inch industrial all-in-one tablet PC with Windows system. Operate smoothly under multiple running web pages. Support customization service for other Windows versions.
| Configuration parameter | Processor | I3-3217u (Support J1900/I3/I5/I7 series processor) |
| Heat dissipation method | Fanless cooling method | |
| RAM | Standard 8GB (Optional 16G) | |
| Hard disk | 128G (SSD) (Optional 256G) | |
| I/O interface | USB: 2xUSB3.0 2xUSB2.0 | |
| Serial port: 2xRS232 （DB9） | ||
| Display interface: HDMI+VGA | ||
| Optional: Bluetooth | ||
| Optional: WIFI module | ||
| The internet | 2x Intel I211 Gigabit Ethernet (RJ-45) | |
| Power supply | Power input | Standard 12V DC |
| Display | LCD screen | 10.1" LED |
| Resolution | 1280*800 | |
| Brightness | 250nits | |
| Color value | 16.7M | |
| Frame rate | 60Hz | |
| Touch screen | Touch mode | Capacitive touch screen |
| Support touch points | Ten points | |
| Click life | 50 million times | |
| structure type | G + G | |
| System | operating system | Windows XP/ 7/8/10/ Linux/Ubuntu |
| Environment | Operating temperature | -10 ° C ~ 60 ° C |
| storage temperature | -20 ° C ~ 70 ° C | |
| Airtight level | Panel IP65 protection rating | |
| Customized service | service | BIOS customization, boot screen LOGO custom / OEM labeling |
| Configuration parameter | power | Less than 50W |
OEM/ODM Services for HXXK TOUCH Industrial Panel PCs
Screen Customization Service
1. High brightness screen: default 400cd/m2, support customization to 1500cd/m2.
2. Photosensitive head: customize the screen brightness automatically based on ambient light.
3. All perspectives: standard 160°, 178° wide viewing angle customized.
4. Touch screen: capacitive touch screen PC, resistive touch screen
5. High-resolution screen: customize higher resolution than a standard LCD screen.
6. Screen size: support to the customized screen.
7. Others: dust-proof, water-proof, explosion-proof, anti-glare.
Other Customization Service
1. Appearance customization: support appearance design, sample customization.
2. Working temperature: standard temp is -10~60°C, we can customize wide temp: -20~70°C.
3. LOGO customization.
4. System software customization: compatible with all software requirements.
5. I/O ports customization: support adding more ports according to your demands.
6. Special materials: for special occasions.
7. IP grade: The industrial monitors can be customized fully sealed dust-proof and waterproof.
